BT30 x ER20M-100mm w/ Mini Nut - Collet Chuck - Eagle Tool & Supply

BT30 x ER20M-100mm w/ Mini Nut - Collet Chuck


Item #: TE1216314
Manufacturer: Techniks
Mfg #: 16314

Technical Specifications:
*Brand Name: Techniks *Capacity: ER20M *Chuck Size: BT30 *Collets Included: No *Coolant Supply: Coolant-thru Spindle with Coolant Capable Retention Knob, sold separately *Head Length/Projection: 100mm *Model Number: 16314 *Mount: BT30 *Nut Diameter: 1.1 *Overall Length: 9.78 *Size/Range: .019 - .551 *Spindle Interface: BT30 *Weight: 1.4 lbs *Wrench Number: TE1204623

Description:
*Techniks Collet Chucks are balanced to 25,000 RPM at G2.5 tolerance *They are individually lab tested for accuracy and balance and come with their individual performance report *Techniks holders achieve 0.0001" or less T.I.R. as measured from the taper to the collet pocket *

Shipping Info:
*Actual Weight - 1.4000 *Dimensions - Height: 6.00 Length: 2.00 Width: 2.00
$181.51
