Ajust-Tru+ Universal Chuck - 15" Plain Mount; 3-Jaw - Eagle Tool & Supply

Ajust-Tru+ Universal Chuck - 15" Plain Mount; 3-Jaw


Item #: HL50B8153
Manufacturer: Buck Chuck
Mfg #: B8153

Technical Specifications:
*Body Width: 5.63 *Body Width including Master Jaw: 5.07 *Bolt Hole Center Distance: 3.00 *Brand Name: Buck Chuck *Chuck Diameter: 15.74 *Chuck Size: 15 *Chuck Style: Scroll Chuck *Class: Lathe Chucks & Accessories *Description: 15" 3 Jaw Scroll Chuck 2 Piece Reversible Jaws *Hole Size: 5.512 *ID Clamping Range: 5.12-14.17 *ID Max.: 14.17 *ID Min.: 5.12 *Jaw Width: 2.50 *Master Jaw Keyway: 0.75 *Maximum Clamping Range: 14.17 *Maximum RPM: 1800 *Model Number: B8153 *Mount: Plain Back *Mount Recess: 12.99 *Mount Recess Depth: 0.35 *Mounting Bolt Radius: 14.25 *Number of Jaws: 3 *OD Clamping Range: 0.79-14.17 *OD Max.: 14.17 *OD Min.: 0.79 *Size of Mounting Bolts: M16 x 2P *Style: Two Piece Reversible American Standard Tongue & Groove *Top Jaw Height: 3.50 *Total Length: 5.63 *Total Width: 4.96 *Trade Name: Buck Chuck *Type: Ajust-Tru+ Universal Chuck *Weight: 246 lbs

Description:
*3-Jaw 2-Pc. Top Reversible Jaw Chucks Require AT Adapters *2, 3, 4 and 6-jaw models offer "dead true" precision of .0005" repeatability on duplicate parts. Up to six times more accurate than conventional chucks.

Shipping Info:
*Commercial Truck - Call for Shipping Charges *Actual Weight - 230.0000
$5,018.96
