Value Collection - #4 Pan Head Torx Sheet Metal Screw - Steel, 3/8" Length Under Head, AISI 1016, ASME B18.6.3, ASME B18.6.4 & SAE J933, Grade 1016-1024, T10 Drive
Item #: 78365525
Brand: Value Collection
Exact Tooling IR#: 04
Features and Benefits
Pan head types have cylindrical heads with rounded edges and flat bearing surfaces. Their low head height and large diameter provide increased driving power.
Torx drive types are also known as star drive fasteners. They have a six-point star recess in the head that increases torque exertion, prevents cam out and boosts fastener life.
Steel is strong and durable but less corrosion resistant than stainless steel. To improve its resistance to corrosion, it may receive additional finishes and coatings.
Type AB screws have the sharp, locating point of type A screws and the thread size of type B screws. They are used to cut threads in thin sheet metal.
| Product Specifications | |
|---|---|
| System of Measurement | Inch |
| Head Type | Pan |
| Screw Size | #4 |
| Length (Inch) | 3/8 |
| Drive Type | Torx |
| Material | Steel |
| Material Grade | 1016-1024 |
| Point Type | Type AB |
| Length Measurement Type | Length Under Head |
| Torx Drive Size | T10 |
| Finish/Coating | Zinc-Plated |
| Fastener Standard | AISI 1016; ASME B18.6.3; ASME B18.6.4; SAE J933 |
