Emuge - M16x2.00 Metric Coarse 6HX 4 Flute Bright Finish Solid Carbide Straight Flute Machine Tap - Modified Bottoming, Right Hand Thread, 110mm OAL, 22mm Thread Length, Oversize, Through Coolant
Item #: 52300209
Brand: Emuge
Model #: C1950901.0116
Exact Tooling IR#: 04
Features and Benefits
Modified bottoming is similar to bottoming, but the chamfer is longer and has more teeth. They are used for threading blind holes and have 2 to 2-1/2 threads.
Solid carbide provides better rigidity than high speed steel. It is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Bright provides a smooth, polished finish on the tool. It increases chip flow in softer materials such as aluminum, wood and plastic.
| Product Specifications | |
|---|---|
| Tap Type | Machine Tap |
| Thread Size (mm) | M16x2.00 |
| Class of Fit | 6HX |
| Number of Flutes | 4 |
| Chamfer | Modified Bottoming |
| Material | Solid Carbide |
| Finish/Coating | Bright |
| Thread Direction | Right Hand |
| Through Coolant | Through Coolant |
| Thread Standard | Metric Coarse |
| Overall Length (Decimal Inch) | 4.33070 |
| Overall Length (mm) | 110.00 |
| Oversize | No |
| Series/List | Rekord A |
| Thread Length (Decimal Inch) | 0.8661 |
| Thread Length (mm) | 22.00 |
| Shank Diameter (Decimal Inch) | 0.4724 |
| Shank Diameter (mm) | 12.00 |
| Shank Length (Decimal Inch) | 3.46 |
| Shank Length (mm) | 88 |
| Square Size (Decimal Inch) | 0.3543 |
| Square Size (mm) | 9.00 |
| Material Application | Aluminum Alloys; Cast Iron; Copper Alloys; Graphite; Hardened Steel; Steel; Tungsten-Copper Alloys |
