KIPP - 5/8-11 Thread, 32mm Overall Length, Socket Mount Leveling Pad - 50mm Base Diameter, Steel Pad, 24mm Hex
Item #: 52198223
Brand: KIPP
Model #: K0395.1A6
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Leveling Pad |
| Thread Size | 5/8-11 |
| Base Diameter (Decimal Inch) | 1.9685 |
| Base Diameter (mm) | 50.00 |
| Load Capacity (kN) | 45.00 |
| Overall Length (mm) | 32.0000 |
| Overall Length (Decimal Inch) | 1.2598 |
| Pad Material | Steel |
| Base Edge Height (Decimal Inch) | 0.2756 |
| Base Edge Height (mm) | 7.00 |
| Hex Size (Decimal Inch) | 0.9449 |
| Hex Size (mm) | 24.0000 |
| Floor To Thread Height (Decimal Inch) | 0.709 |
| Floor To Thread Height (mm) | 18.0 |
