Walter - TungMeister 0.312" Stepped Shank Milling Tip Insert Holder & Shank - 0.3" Neck Diam, S05 Neck Thread, 0.3" Nose Diam, 2-1/2" OAL, Steel VSS Tool Holder
Item #: 32224479
Brand: Walter
Model #: 6864082
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Series | TungMeister |
| Shank Type | Stepped Shank |
| Shank Diameter (Decimal Inch) | 0.3120 |
| Neck Diameter (Decimal Inch) | 0.3000 |
| Neck Thread Size | S05 |
| Nose Diameter (Decimal Inch) | 0.3000 |
| Toolholder Material | Steel |
| Overall Length (Decimal Inch) | 2.5000 |
| Head Length (Decimal Inch) | 0.5900 |
| Maximum Diameter (Decimal Inch) | 0.3120 |
| Shank Shape | Round |
| Toolholder Style | VSS |
| Cutting Direction | Right Hand |
| Corner Radius (mm) | 0.20 |
| Corner Radius (Decimal Inch) | 0.008 |
| Coating Process | CVD |
| Coating | TiCN+Al2O3+(TiCN) |
| Chipbreaker | B57 |
| Manufacturer's Grade | WKP25S |
| Length (mm) | 5.2 |
| Relief Angle | 7 |
| Length (Decimal Inch) | 0.2050 |
| Thickness (mm) | 2.38 |
| Thickness (Decimal Inch) | 0.0940 |
